Description
ROG-STRIX-1000G
Intel Specification
ATX12V
Dimensions
16 x 15 x 8.6 Centimeter
Efficiency
80Plus Gold
Protection Features
OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials
ROHS
AC Input Range
100-240Vac
RGB Connector
NO
Thermal Features
ROG Thermal Solution
Fan Size
135 mm
DC Output Voltage
+3.3V +5V +12V -12V +5Vsb
Maximum Load
20A 20A 70A 0.3A 3A
Combined Load
100W 100W 840W 3.6W 15W
Total Output
850W
Connectors
MB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 6+2-pin x 6
SATA x 8
PERIPHERAL x 6
CPU 4+4-pin x 2
PCI-E 6+2-pin x 6
SATA x 8
PERIPHERAL x 6
Package Contents
Power Cord x 1
Motherboard Power Cable x 1 (610mm)
CPU Cable 1000mm x 2 (1000mm)
PCI-E Cable x 3 (675mm)
SATA Cable x 2 (810mm/860mm)
Peripheral x 2 (450mm)
ROG badge x 2
ROG logo magnet x 1
ROG label x 3
Motherboard Power Cable x 1 (610mm)
CPU Cable 1000mm x 2 (1000mm)
PCI-E Cable x 3 (675mm)
SATA Cable x 2 (810mm/860mm)
Peripheral x 2 (450mm)
ROG badge x 2
ROG logo magnet x 1
ROG label x 3
Weight
Single Card (KG) : 1.825
Product Weight (with packing) (KG) 3.42
Product Weight (with packing) (KG) 3.42
